inverter ac/dc square wave tig welding machine with pulse

Price:	50.0~100.0 USD
Payment Terms:	T/T,L/C,D/A,D/P
Place of Origin:	Shanghai, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Production Capacity: 10000 pcs per month

Delivery Date: within 3 days

Packing: standard carton

1 comprehensive function and adjustment design can meet the request of high quality welding
2 Base current, pulse current, up slope, down slope, puls

1 comprehensive function and adjustment design can meet the request of high quality welding

2 Base current, pulse current, up slope, down slope, pulse frequency, pulse width can be adjusted continuously.

3 Speedy up slope pulse current and down slope pulse current. Excellent effect in thin metal sheet welding. Especially applicable for vacuum flask and bicycle industry.

4 First optional equipment for automatic welding system.

Model	ACDC200P	ACDC315P
Inputpower voltage(V)	AC220V±15%	AC380V±15%
Inputvoltage frequency(Hz)	50/60	50/60
Ratedinput power capacity(KW)	4.5	9
Ratedinput current(A)	20.7	13.6
Noload voltage(V)	56	56
Arc-starting	HF	HF
Outputcurrent range	10-200	20-315
Ratedoutput voltage(V)	18	22.6
Pre-flowtime(S)	0-2	0-2
Downslope time	0-5	0-5
Pulsecurrent(A)	20-200	20-315
Pulsefrequency(Hz)	1-70	1-70
Pulsewidth(%)	10-90	10-90
Dutycycle(%)	60	60
Noload consumption(W)	60	60
Efficiency(%)	85	85
Powerfactor	0.93	0.93
Insulationclass	B	B
Protectionclass	IP21	IP21
Weight(kg)	20	32
Dimension(mm)	498×327×360	560×361×360
